| Model | MU-N12 | |||
| Main unit/Expansion unit | Expansion unit | |||
| Response time | Depends on the connected sensor model*1 | |||
| Expansion units | Up to 4 expansion units*2 | |||
| I/O | Control output | 4 max., NPN open collector/PNP open collector selectable, 24 V or less, Main unit: 50 mA or less*3, Expansion unit: 20 mA or less, Residual voltage: 2 V or less, N.O./N.C. selectable *1*4 | ||
| External input | 5 max., Short-circuit current: NPN: 1 mA or less, PNP: 2 mA or less, For the applied voltage, see wiring diagrams (page 3 of the instruction manual) *1*4 | |||
| Analog output | – | |||
| Protection circuit | Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection | |||
| Power supply | Power voltage | 24 VDC, ripple (P-P) 10% or less, Class 2 or LPS | ||
| Current consumption | 55 mA or less (without load)*5 | |||
| Sensor connection specification | Allowable sensor current | 150 mA or less | ||
| N-bus connection specification | Allowable passing current | 900 mA or less | ||
| Environmental resistance | Ambient temperature | -20 to +50 °C -4 to 122 °F (No freezing) | ||
| Relative humidity | 35 to 85 % RH (No condensation) | |||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions | |||
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions | |||
| Material | Case and dust cover: Polycarbonate Buttons: Polyacetal Display panel: PMMA | |||
| Weight | Approx. 70 g | |||
| *1 The response time, as well as the types and number of inputs and outputs that are available, vary depending on the connected sensor model. For details, see the specific “MU-N Series User’s Manual” for the model that will be connected. *2 Up to 5 N-bus devices, including the main unit (or network unit), can be linked together. *3 20 mA or less: When using the expansion unit. *4 For more information on Control output, External input, and Analog output wire allocation, please refer to the table of “Power Cable Pin Layout” on page 3 of this manual. *5 1185 mA or less when a sensor is attached, 4 outputs (with loads) are used, and expansion units are connected. | ||||
Bộ điều khiển cảm biến Keyence MU-N12
Multi-Sensor Controller, Expansion Unit
SKU: MU-N12
Hãng sản xuất: Keyence
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
Thông tin bổ sung
| Thương hiệu | |
|---|---|
| Thời gian bảo hành | 1 Năm |
| Yêu cầu tư vấn | 0342 678 887(Call/Zalo) |
