Biến tần Hybrid Growatt SPH 3000TL BL-UP 1 Pha 220V

SKU: SPH 3000TL BL-UP
Nhà sản xuất: Growatt
Chất lượng: Mới 100%
Bảo hành: 5 năm
Chứng từ: CO/CQ, hóa đơn VAT

Thông tin cần biết thêm:
✓ Hỗ trợ cài đặt & sửa chữa inverter trong quá trình sử dụng
✓ Nhận lắp đặt tủ AC, DC hòa lưới theo yêu cầu
✓ Luôn có giá tốt cho dự án nhà thầu trọn gói
Báo giá
Mã: SPH 3000TL BL-UP Danh mục: , Thẻ:
DatasheetSPH3000TL BL-UP
Input data(PV)
Max. recommended PV power (for module STC)6000W
Max. DC voltage550V
Start voltage120V
MPP voltage range120-550V/360V
No. of MPP trackers2
No. of PV strings per MPP tracker1
Max. input current per MPP tracker13.5A
Max. short-circuit current per MPP tracker16.5A
Output data(AC)
AC nominal power3000W
Max. AC apparent power3000VA
Nominal AC voltage (range)230V/（180Vac-270Vac)
AC grid frequency (range)50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
Max. output current16A
Adjustable power factor0.8leading…0.8lagging
THDi<3%
AC grid connection typeSingle phase
Battery data (DC)
Battery voltage range42~59V
Max charging and discharging current66A
Continuous charging and
discharging power3000W
Type of batteryLithium /Lead-acid
Backup power(AC)
Max. AC output power3000W
Max. output current17.4A
Nominal AC output voltage230Vac
Nominal AC output frequency50/60HZ
THDv<3%
Switch time<10ms
Efficiency
MAX. efficiency97.20%
European efficiency97%
MPPT efficiency≥99.5%
Protection devices
DC switchYes
DC reverse polarity protectionYes
AC/DC surge protectionYes
Battery reverse protectionYes
AC short-circuit protectionYes
Ground fault monitoringYes
Grid monitoringYes
Anti-islanding protectionYes
Residual-current monitoring unitYes
Insulation resistance monitoringYes
General data
Dimensions (W / H / D)458/565/188mm
Weight31kg
Operating temperature range-25°C+60°C
Nighttime power consumption< 10 W
TopologyTransformerless
CoolingNatural
Protection degreeIP65
Relative humidity0~100%
Altitude2000m
PV DC ConnectionH4/MC4(Optional)
Battery DC ConnectionOT Terminal
AC connectionConnector
DisplayLCD+LED
Interfaces:RS485/CAN/USBYes
Monitor : RF/WIFI/GPRSOptional
Warranty: 5 years / 10 yearsYes/Optional
CE, IEC62109, G98/G99, VDE0126-1-1, AS4777,  CEI 0-21, VDE-AR-N4105, UTE C 15-712，EN50549, IEC 61727, IEC 62116, IEC 62040, C10/11, NRS 097-2-1
