Nominal size in mm
63, 80
Accuracy class
Pressure: 2.5 (EN 837-1)
Temperature: 2 (EN 13190)
Scale ranges
Pressure: 0 … 4 to 0 … 10 bar
Temperature: 0 … 120 °C
Pressure limitation
¾ x full scale value
Temperature measuring range
40 … 80 °C
Storage and transport temperature
-20 … +60 °C
Measuring elements
Pressure: Bourdon tube, copper alloy
Temperature: Bimetal coil
Process connection
Copper alloy, G ¼ B male
Back mount (BM)
Lower mount (LM)
Shut-off valve
Copper alloy, G ¼ female
R ½ ISO 7 (male)
Case
Plastic, black
Movement
Copper alloy
Dial
Plastic , black, white lettering, indication of limit ranges by
standard colour scale
Pressure scale position: Top
Temperature scale position: Bottom
Pointer
Pressure: Plastic, blue
Temperature: Plastic, red
Window
Plastic, crystal-clear, snap-fitted
Options
Shut-off valve: Customer-specific process connections
Other pressure and temperature units
Window with red mark pointer
White dial, black lettering, indication of limit ranges by standard colour scale
