| Nominal diameter | 60 and 75 mm |
| Accuracy | ±1.5 % of full scale |
| Scale range (MPa, kPa, bar) | 60mm : -0.1 ~ 0.2, 0.4, 1.0, 1.5, 2.0 MPa |
| 0 ~ 2.5, 0 ~ 3.5 MPa | |
| 75mm : -0.1 ~ 0.2, 0.4, 1.5 MPa | |
| 0 ~ 3.5 MPa | |
| Working pressure | Steady : 75 % of full scale |
| Over range protection : 130 % of full scale | |
| Working temperature | Ambient : -20 ~ 60 ℃ |
| Fluid : Max. 60 °C | |
| Temperature effect | Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately |
| ±0.4 % per 10℃ of full scale | |
| Pressure connection | Brass |
| Element | Brass |
| C type bourdon tube | |
| Case | Black finished steel |
| Window | Polycarbonate (60 mm) Glass (Only 75 mm) |
| Movement | Brass |
| Dial | White aluminium with black graduations |
| Pointer | Black painted aluminium alloy |
| Process connection | 7/16″ UNF |
| ¼” PT, NPT and PF | |
| ⅜” PT, NPT and PF (Only 75 mm) |
