| Nominal diameter | 80 mm |
| Accuracy | ±1.0 % of full scale |
| Scale range (MPa, kPa, bar) | -0.1 ~ 0 to 0 ~ 6 MPa |
| Working temperature | Ambient : -20 ~ 60 ℃ |
| Fluid : Max. 60 °C | |
| Temperature effect | Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately |
| ±0.4 % per 10 ℃ of full scale | |
| Pressure connection | Brass |
| Element | Brass |
| Case | Bronze |
| Cover | Black finished bronze |
| Window | Laminated safety glass |
| Movement | 304SS |
| Dampers vibration and pulsation | |
| Dial | White aluminium with black graduations |
| Pointer | Black painted aluminium alloy |
| Process connection | ⅛” PT, NPT and PF |
| ¼” PT, NPT and PF | |
| ⅜” PT, NPT and PF | |
| M12 x 1.5 |
