Nominal diameter
160 mm
Accuracy
±1.0 % of full scale
±1.6 % of full scale
Scale range (MPa, kPa, bar, mbar)
0 ~ 25 kPa to 0 ~ 0.25 MPa (P651 model)
0 ~ 0.4 MPa to 0 ~ 2.0 MPa (P652 model)
Max. working pressure (Static pressure)
Max. 10 Mpa
Working temperature
Ambient: -20 ~ 65 °C
Fluid: Max. 100 °C
Degree of protection
EN60529/IEC529/IP67
Temperature effect
Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately ±0.5 % per 10 ℃ of full scale
Pressure connection
Stainless steel (316SS), Monel and Hastelloy-C
Element
Bellows
Stainless steel (316L SS), Monel and Hastelloy-C
Case
Stainless steel (304SS)
Bezel ring
Stainless steel (304SS)
Bayonet type
Window
Polycarbonate
Dial
White aluminium with black graduations
Pointer
Black painted aluminium alloy
Conduit connection
M20 x 1.5
Process connection
¼” NPT(F)
½” NPT(F) at 3-way and 5-way manifold valve
Standard accessories
Mounting bracket for 2″ pipe
mounting with silver gray finished steel
Certificates
Pressure equipment directive (2014/68/EU) Annex III Module H
Option
Remote seal
Mounting bracket with 316SS for 2″ pipe mounting
3-way manifold valve (316SS, Monel)
5-way manifold valve (316SS, Monel)
