Special features
3-A certificated
Suitable for SIP and CIP
All stainless steel and welded construction
Nominal diameter
50, 63, 80 and 100 mm
Accuracy
P752 (50 mm): ±3.0 % of full scale
P752 (63 mm) and P752 (80 mm): ±1.6 % of full scale
P752 (100 mm): ±1.0 % of full scale
Scale range
-0.1 ~ 7 Mpa
Working pressure
Steady pressure: 75 % of full scale value
Fluctuating pressure: 67 % of full scale value
Working temperature
Ambient: -25 ~ 65 °C
Fluid: Max.121 °C
Temperature effect
Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately ±0.5 % per 10 ℃ of full scale
Process connection
¾”, 1″, 1½” and 2″
Low and back
Diaphragm and seal housing
Diaphragm: Stainless steel (316L SS)
Surface roughness: ≤ Ra : 0.8 ㎛
Seal housing: Stainless steel (316SS)
Case
Stainless steel (304SS)
Electropolished with pressure relief
Cover
50 mm: Twist-lock polycarbonate (Diameter 50 mm)
63, 80 and 100 mm: Stainless steel 304SS
Window
Safety glass (63, 80 and 100 mm)
Polycarbonate (50 mm)
Movement
Stainless steel
Dial
White aluminium with black and red graduations, dual pressure scale
Pointer
Black painted aluminium alloy
Helium leak rate
Tested to confirm leakage rates of less than 10-8 mbar •ℓ /sec
System filling
Food grade oil (FDA certified)
Option
Material of wetted parts : electropolished 316L SS
