| Datasheet | 33000TL3-S |
| Input Data | |
| Max recommended PV Power (for module STC) | 41250W |
| Max DC voltage | 1000V |
| Start Voltage | 250V |
| MPPT voltage range | 200V-1000V |
| Nominal voltage | 580V |
| Max. input current | 38A / 38A |
| Max. input current per string | 12A |
| Number of MPP trackers / strings per MPP tracker | 2/4 |
| Output (AC) | |
| Rated AC output power | 33kW |
| Max. AC apparent power | 36.6kVA |
| Max. output current | 53A |
| AC nominal voltage | 230V/400V |
| AC grid frequency | 50Hz/60Hz |
| Power factor | 0.8 leading – 0.8 lagging |
| THDi | <3% |
| AC grid connection type | 3W+N+PE |
| Efficiency | |
| Max.efficiency | 98.90% |
| Euro – eta | 98.40% |
| MPPT efficiency | 99.50% |
| Protection Devices | |
| DC reverse polarity protection | yes |
| DC Switch | yes |
| DC Surge protection | Type II |
| Ground fault monitoring | yes |
| Output short circuit protection | yes |
| AC Surge protection | Type II |
| String Fuse protection | yes |
| String fault monitoring | yes |
| Anti-PID protection | yes |
| General Data | |
| Dimensions (W / H / D) in mm | 470x754x270mm |
| Weight | 48kg |
| Operating temperature range | -25 °C…+60 °C |
| Noise emission (typical) | ≤40 dB(A) |
| Altitude | 4000m |
| Self-consumption night | < 1W |
| Topology | Transformerless |
| Cooling concept | Smart cooling |
| Environmental Protection Rating | IP65 |
| Relative humidity | 0~100% |
| Features | |
| Display | Graphic LCD |
| Interfaces: RS232/R485/WiFi/LAN/GPRS | yes / yes / opt / opt / opt |
| Warranty:5 years / 10 years | yes / opt |
| CE, IEC 62109-1/2, IEC 61727, IEC 62116, VDE 0126-1-1, Greece, VFR 2014, CEI 0-21, CEI 0-16, VDE-AR-N4105, EN50438, G59/3, AS 4777, PEA, IEC 60529, IEC 60068, IEC 61683, DRRG |
Download tài liệu: Hướng dẫn cài đặt Wifi Growatt ShineWiFi-S
Growatt Series
Bảng hướng dẫn lựa chọn Inverter hòa lưới Growatt phù hợp với nhu cầu sử dụng| Mã sản phẩm | Công suất | Điện áp ngõ ra |
|---|
| MIN 3000TL-X | 3kW | 1 Pha 220V |
| MIN 5000TL-X | 5kW | 1 Pha 220V |
| MIN 6000TL-X | 6kW | 1 Pha 220V |
| MIN 8000TL-X | 8kW | 1 Pha 220V |
| 8000MTL-S | 8kW | 1 Pha 220V |
| MIN 10000TL-X | 10kW | 1 Pha 220V |
| MOD 10KTL3-X | 10KW | 3 Pha 380V |
| 10000TL3-S | 10KW | 3 Pha 380V |
| MOD 15KTL3-X | 15kW | 3 Pha 380V |
| MID 15KTL3-X | 15kW | 3 Pha 380V |
| MID 20KTL3-X | 20kW | 3 Pha 380V |
| MID 22KTL3-X | 22kW | 3 Pha 380V |
| MID 25KTL3-X | 25kW | 3 Pha 380V |
| MID 30KTL3-X | 30kW | 3 Pha 380V |
| MID 33KTL3-X | 33kW | 3 Pha 380V |
| MID 40KTL3-X | 40kW | 3 Pha 380V |
| MAC 50KTL3-X LV | 50kW | 3 Pha 380V |
| MAC 60KTL3-X LV | 60kW | 3 Pha 380V |
| MAX 70KTL3 LV | 70kW | 3 Pha 380V |
| MAX 80KTL3 LV | 80kW | 3 Pha 380V |
| MAX 110KTL3 LV | 110kW | 3 Pha 380V |
