Name: Cảm biến cửa IFM MN508S
SKU: MN508S
Price: 2128000 VND
Availability: InStock

Product characteristics
Output function	2 x normally open, 1 x normally closed; (potential-free)
Sensing range [mm]	8; (with defined actuator)
Housing	rectangular
Dimensions [mm]	88 x 13.1 x 25
Application
Design	coded target
Type of operation	permanent operation
Application	for safety-related applications
Electrical data
Operating voltage [V]	24 DC
Rated insulation voltage [V]	60
Protection class	III
Reverse polarity protection	no
Internal resistance (Ri) [Ω]	10; (1 W)
Outputs
Output function	2 x normally open, 1 x normally closed; (potential-free)
Permanent current rating of switching output DC [mA]	50
Switching frequency DC [Hz]	150
Output data	Interface type A
Short-circuit proof	no
Max. capacitive load CL_max [nF]	20
Detection zone
Sensing range [mm]	8; (with defined actuator)
Safe switching-off distance s(ar) [mm]	20
Response times
Response time to safety request [ms]	10
Max. fall time [ms]	0.1
Max. make time incl. bounce [ms]	0.6
Operating conditions
Applications	class C to EN 60654-1 weatherproof application
Ambient temperature [°C]	-25…80
Note on ambient temperature	operational life ≤ 87600 h
Ambient temperature [°C]	10…40
Note on ambient temperature	operational life ≤ 175200 h
Max. relative air humidity [%]	briefly: 5…95 %; permanent: 5…70 %
Air pressure [kPa]	80…106
Max. height above sea level [m]	2000
Salt spray	no
Protection	IP 67; IP 69K; (protected cable laying)

Thông tin bổ sung

Cảm biến cửa IFM MN508S
