| Product characteristics | |||
|---|---|---|---|
| Output function | normally open / normally closed; (selectable) | ||
| Sensing range [mm] | 20 | ||
| Housing | cylindrical | ||
| Dimensions [mm] | Ø 34 / L = 82 | ||
| Electrical data | |||
| Operating voltage [V] | 10…55 DC | ||
| Protection class | II | ||
| Reverse polarity protection | yes | ||
| Outputs | |||
| Output function | normally open / normally closed; (selectable) | ||
| Max. voltage drop switching output DC [V] | 4.6 | ||
| Minimum load current [mA] | 4 | ||
| Max. leakage current [mA] | 0.5 | ||
| Permanent current rating of switching output DC [mA] | 400 | ||
| Switching frequency DC [Hz] | 300 | ||
| Short-circuit protection | yes | ||
| Type of short-circuit protection | pulsed | ||
| Overload protection | yes | ||
| Detection zone | |||
| Sensing range [mm] | 20 | ||
| Real sensing range Sr [mm] | 20 ± 10 % | ||
| Operating distance [mm] | 0…16.2 | ||
| Accuracy / deviations | |||
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 | ||
| Hysteresis [% of Sr] | 3…15 | ||
| Switch point drift [% of Sr] | -10…10 | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…80 | ||
| Protection | IP 67 | ||
| Mechanical data | |||
| Weight [g] | 415 | ||
| Housing | cylindrical | ||
| Mounting | non-flush mountable | ||
| Dimensions [mm] | Ø 34 / L = 82 | ||
| Materials | PBT | ||
| Displays / operating elements | |||
| Display |
| ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Remarks | |||
| Pack quantity | 1 pcs. | ||
| Electrical connection | |||
| Connection | Cable: 6 m, PUR / PVC; 2 x 0.5 mm² | ||
Cảm biến tiệm cận IFM IB5161
2.730.000 ₫
SKU: IB5161
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
