| Product characteristics | |||
|---|---|---|---|
| Electrical design | PNP/NPN | ||
| Output function | normally closed | ||
| Sensing range [mm] | 1 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M8 x 1 / L = 35 | ||
| Electrical data | |||
| Operating voltage [V] | 10…36 DC | ||
| Protection class | III | ||
| Reverse polarity protection | yes | ||
| Outputs | |||
| Electrical design | PNP/NPN | ||
| Output function | normally closed | ||
| Max. voltage drop switching output DC [V] | 3.5 | ||
| Minimum load current [mA] | 4 | ||
| Max. leakage current [mA] | 0.8 | ||
| Permanent current rating of switching output DC [mA] | 200 | ||
| Switching frequency DC [Hz] | 1300 | ||
| Short-circuit protection | no | ||
| Overload protection | no | ||
| Detection zone | |||
| Sensing range [mm] | 1 | ||
| Real sensing range Sr [mm] | 1 ± 10 % | ||
| Operating distance [mm] | 0…0.81 | ||
| Accuracy / deviations | |||
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 | ||
| Hysteresis [% of Sr] | 1…15 | ||
| Switch point drift [% of Sr] | -10…10 | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…80 | ||
| Protection | IP 67 | ||
| Mechanical data | |||
| Weight [K40] | 47.6 | ||
| Housing | threaded type | ||
| Mounting | flush mountable | ||
| Dimensions [mm] | M8 x 1 / L = 35 | ||
| Thread designation | M8 x 1 | ||
| Materials | brass white bronze coated; PBT | ||
| Tightening torque [Nm] | A = 5 mm: 1 Nm; B: 2 Nm | ||
| Displays / operating elements | |||
| Display |
| ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Remarks | |||
| Pack quantity | 1 pcs. | ||
| Electrical connection | |||
| Connection | Cable: 2 m, PVC; 2 x 0.14 mm² | ||
Cảm biến tiệm cận IFM IE5208
1.910.000 ₫
SKU: IE5208
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
