| Product characteristics | |||
|---|---|---|---|
| Output function | normally open | ||
| Sensing range [mm] | 22 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M30 x 1.5 | ||
| Electrical data | |||
| Operating voltage [V] | 20…250 AC/DC | ||
| Protection class | I | ||
| Reverse polarity protection | no | ||
| Outputs | |||
| Output function | normally open | ||
| Max. voltage drop switching output DC [V] | 6 | ||
| Max. voltage drop switching output AC [V] | 6.5 | ||
| Minimum load current [mA] | 5 | ||
| Max. leakage current [mA] | 1 (250 V AC) / 0.8 (140 V AC) / 0.8 (24 V DC) | ||
| Permanent current rating of switching output AC [mA] | 250; (350 (…50 °C)) | ||
| Permanent current rating of switching output DC [mA] | 100 | ||
| Short-time current rating of switching output [mA] | 2200; (20 ms / 0,5 Hz) | ||
| Switching frequency AC [Hz] | 25 | ||
| Switching frequency DC [Hz] | 70 | ||
| Short-circuit proof | no | ||
| Overload protection | no | ||
| Detection zone | |||
| Sensing range [mm] | 22 | ||
| Real sensing range Sr [mm] | 22 ± 10 % | ||
| Operating distance [mm] | 0…17.6 | ||
| Accuracy / deviations | |||
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.48 / copper: 0.4 | ||
| Hysteresis [% of Sr] | 3…20 | ||
| Switch point drift [% of Sr] | -10…10 | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…70 | ||
| Protection | IP 67 | ||
| Mechanical data | |||
| Weight [K40] | 217.5 | ||
| Housing | threaded type | ||
| Mounting | non-flush mountable | ||
| Dimensions [mm] | M30 x 1.5 | ||
| Thread designation | M30 x 1.5 | ||
| Materials | brass white bronze coated; sensing face: PBT; connector housing: PA | ||
| Displays / operating elements | |||
| Display |
| ||
| Electrical connection | |||
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting | ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Remarks | |||
| Remarks |
| ||
| Pack quantity | 1 pcs. | ||
| Electrical connection – plug | |||
| Connector: 1 x 1/2″ | |||
Cảm biến tiệm cận IFM II0341
2.780.000 ₫
SKU: II0341
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
