| Product characteristics | |||||
|---|---|---|---|---|---|
| Type of light | infrared light | ||||
| Housing | rectangular | ||||
| Dimensions [mm] | 35 x 24 x 11 | ||||
| Application | |||||
| Function principle | Through-beam sensor | ||||
| Electrical data | |||||
| Operating voltage [V] | 10…30 DC | ||||
| Current consumption [mA] | < 19 | ||||
| Protection class | III | ||||
| Reverse polarity protection | yes | ||||
| Type of light | infrared light | ||||
| Wave length [nm] | 880 | ||||
| Outputs | |||||
| Overload protection | yes | ||||
| Detection zone | |||||
| Transmitter / receiver | transmitter | ||||
| Range [m] | < 5 | ||||
| Operating conditions | |||||
| Ambient temperature [°C] | -25…60 | ||||
| Protection | IP 67 | ||||
| Mechanical data | |||||
| Weight [g] | 40.2 | ||||
| Housing | rectangular | ||||
| Dimensions [mm] | 35 x 24 x 11 | ||||
| Materials | housing: ABS; fixture: diecast zinc; LED window: SEPS; pushbutton: SEPS | ||||
| Lens material |
| ||||
| Lens alignment | front lens | ||||
| Displays / operating elements | |||||
| Display |
| ||||
| Accessories | |||||
| Accessories (supplied) |
| ||||
| Remarks | |||||
| Remarks |
| ||||
| Pack quantity | 1 pcs. | ||||
| Electrical connection | |||||
| Connection | Connector: 1 x M8 | ||||
Cảm biến quang IFM OJ5073 (thu phát chung)
2.180.000 ₫
Excellent price/performance ratio
Simple alignment due to visible red light
Low-cost systems for fixing and mounting
High switching frequency for fast processes
Robust stainless steel sleeves in the fixing holes
SKU: OJ5073
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
