| Product characteristics | |||||
|---|---|---|---|---|---|
| Type of light | infrared light | ||||
| Dimensions [mm] | 736 x 50 x 60 | ||||
| Application | |||||
| Protective function | access prevention body protection | ||||
| Electrical data | |||||
| Operating voltage tolerance [%] | 20 | ||||
| Operating voltage [V] | 24 DC | ||||
| Current consumption [mA] | 250 | ||||
| Protection class | III | ||||
| Reverse polarity protection | yes | ||||
| Power-on delay time [s] | < 10 | ||||
| Type of light | infrared light | ||||
| Wave length [nm] | 950 | ||||
| Outputs | |||||
| Electrical design | PNP | ||||
| Number of OSSD outputs | 2 | ||||
| Max. current load per OSSD output [mA] | 500; (24 V) | ||||
| Short-circuit protection | yes | ||||
| Detection zone | |||||
| Protected area height [mm] | 510 | ||||
| Number of beams | 2 | ||||
| Protection area width (low light intensity) [m] | 0…6 | ||||
| Protection area width (high light intensity) [m] | 0…6 | ||||
| Active/passive system | yes | ||||
| Response times | |||||
| Response time [ms] | 10 | ||||
| Operating conditions | |||||
| Applications | class C to EN 60654-1 weatherproof application | ||||
| Ambient temperature [°C] | -10…55 | ||||
| Max. relative air humidity [%] | 95 | ||||
| Protection | IP 65 | ||||
| Safety classification | |||||
| ESPE type (IEC 61496-1) | 4 | ||||
| ISO 13849-1 | category 4, PL e | ||||
| IEC 61508 | SIL 3 | ||||
| IEC 62061 | SIL cl 3 | ||||
| Mission time TM [h] | 175200 | ||||
| Safety-related reliability PFHD [1/h] | 4.8E-09 | ||||
| Mechanical data | |||||
| Weight [K40] | 6010 | ||||
| Dimensions [mm] | 736 x 50 x 60 | ||||
| Materials | housing: aluminium; front lens: PC | ||||
| Length L [mm] | 736 | ||||
| Displays / operating elements | |||||
| Display |
| ||||
| Accessories | |||||
| Accessories (supplied) |
| ||||
| Remarks | |||||
| Notes | For 8-pole sockets the core colours are not standardised.; Please note the wiring of the sensor and the sockets (see data sheet). | ||||
| Pack quantity | 1 pcs. | ||||
| Electrical connection | |||||
| Connection | Connector: 1 x M12; Maximum cable length: 100 m; for wire cross-section 1 mm² | ||||
Cảm biến vùng IFM OY901S 51x600cm 24VDC
25.530.000 ₫
SKU: OY901S
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
Thông tin bổ sung
| Thương hiệu | |
|---|---|
| Thời gian bảo hành | 5 Năm |
