| Product characteristics | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Number of inputs and outputs | Number of digital outputs: 2; Number of analogue outputs: 1 | ||||||||
| Measuring range [ml/min] | 5…3000 | ||||||||
| Process connection | threaded connection G 1/4 DN6 flat seal | ||||||||
| Application | |||||||||
| Special feature | Gold-plated contacts | ||||||||
| Application | totaliser function; for industrial applications | ||||||||
| Installation | connection to pipe by means of an adapter | ||||||||
| Media | conductive liquids; water; hydrous media | ||||||||
| Note on media |
| ||||||||
| Medium temperature [°C] | 0…60 | ||||||||
| Pressure rating [bar] | 10 | ||||||||
| Pressure rating [Mpa] | 1.2 | ||||||||
| MAWP (for applications according to CRN) [bar] | 7.3 | ||||||||
| Electrical data | |||||||||
| Operating voltage [V] | 18…30 DC; (according to EN 50178 SELV/PELV) | ||||||||
| Current consumption [mA] | < 80 | ||||||||
| Protection class | III | ||||||||
| Reverse polarity protection | yes | ||||||||
| Power-on delay time [s] | 5 | ||||||||
| Inputs / outputs | |||||||||
| Number of inputs and outputs | Number of digital outputs: 2; Number of analogue outputs: 1 | ||||||||
| Inputs | |||||||||
| Inputs | counter reset | ||||||||
| Outputs | |||||||||
| Total number of outputs | 2 | ||||||||
| Output signal | switching signal; analogue signal; pulse signal; IO-Link; (configurable) | ||||||||
| Electrical design | PNP/NPN | ||||||||
| Number of digital outputs | 2 | ||||||||
| Output function | normally open / normally closed; (parameterisable) | ||||||||
| Max. voltage drop switching output DC [V] | 2 | ||||||||
| Permanent current rating of switching output DC [mA] | 200 | ||||||||
| Number of analogue outputs | 1 | ||||||||
| Analogue current output [mA] | 4…20; (scalable) | ||||||||
| Max. load [Ω] | 500 | ||||||||
| Analogue voltage output [V] | 0…10; (scalable) | ||||||||
| Min. load resistance [Ω] | 2000 | ||||||||
| Pulse output | flow rate meter | ||||||||
| Short-circuit protection | yes | ||||||||
| Type of short-circuit protection | pulsed | ||||||||
| Overload protection | yes | ||||||||
| Measuring/setting range | |||||||||
| Measuring range [ml/min] | 5…3000 | ||||||||
| Display range [ml/min] | -1999…3600 | ||||||||
| Resolution [ml/min] | 1 | ||||||||
| Set point SP [ml/min] | 20…3000 | ||||||||
| Reset point rP [ml/min] | 5…2984 | ||||||||
| Analogue start point ASP [ml/min] | 0…2400 | ||||||||
| Analogue end point AEP [ml/min] | 600…3000 | ||||||||
| Low flow cut-off LFC [ml/min] | < 60 | ||||||||
| Volumetric flow quantity monitoring | |||||||||
| Pulse value | 0.001…3000 l | ||||||||
| Pulse length [s] | 0,008…2 | ||||||||
| Temperature monitoring | |||||||||
| Measuring range [°C] | -20…80 | ||||||||
| Resolution [°C] | 0.2 | ||||||||
| Set point SP [°C] | -19.2…80 | ||||||||
| Reset point rP [°C] | -19.6…79.6 | ||||||||
| Analogue start point [°C] | -20…60 | ||||||||
| Analogue end point [°C] | 0…80 | ||||||||
| In steps of [°C] | 0.2 | ||||||||
| Accuracy / deviations | |||||||||
| Flow monitoring | |||||||||
| Accuracy (in the measuring range) | ± (2 % MW + 0,5 % MEW) | ||||||||
| Repeatability | ± 0,2% MEW | ||||||||
| Temperature monitoring | |||||||||
| Accuracy [K] | ± 2,5 (Q > 0,5 l/min) | ||||||||
| Response times | |||||||||
| Flow monitoring | |||||||||
| Response time [s] | 0.15; (dAP = 0, T19) | ||||||||
| Delay time programmable dS, dr [s] | 0…50 | ||||||||
| Damping for the switching output dAP [s] | 0…5 | ||||||||
| Temperature monitoring | |||||||||
| Dynamic response T05 / T09 [s] | T09 = 40 (Q > 1 l/min) | ||||||||
| Software / programming | |||||||||
| Parameter setting options | Flow monitoring; quantity meter; Preset counter; Temperature monitoring; hysteresis / window; normally open / normally closed; switching logic; current/voltage/pulse output; start-up delay; display can be deactivated; Display unit | ||||||||
| Interfaces | |||||||||
| Communication interface | IO-Link | ||||||||
| Transmission type | COM2 (38,4 kBaud) | ||||||||
| IO-Link revision | 1.1 | ||||||||
| SDCI standard | IEC 61131-9 | ||||||||
| Profiles | Smart Sensor: Process Data Variable; Device Identification, Device Diagnosis | ||||||||
| SIO mode | yes | ||||||||
| Required master port type | A | ||||||||
| Process data analogue | 3 | ||||||||
| Process data binary | 2 | ||||||||
| Min. process cycle time [ms] | 4 | ||||||||
| Supported DeviceIDs |
| ||||||||
| Operating conditions | |||||||||
| Ambient temperature [°C] | -10…60 | ||||||||
| Storage temperature [°C] | -25…80 | ||||||||
| Protection | IP 67 | ||||||||
| Mechanical data | |||||||||
| Weight [g] | 536.5 | ||||||||
| Materials | stainless steel (1.4404 / 316L); PBT-GF20; PC; FKM; TPE | ||||||||
| Materials (wetted parts) | stainless steel (1.4404 / 316L); PEEK; FKM | ||||||||
| Process connection | threaded connection G 1/4 DN6 flat seal | ||||||||
| Displays / operating elements | |||||||||
| Display |
| ||||||||
| Remarks | |||||||||
| Remarks |
| ||||||||
| Pack quantity | 1 pcs. | ||||||||
| Electrical connection | |||||||||
| Connection | Connector: 1 x M12; Contacts: gold-plated | ||||||||
Cảm biến lưu lượng IFM SM4000 10 bar
21.882.000 ₫
SKU: SM4000
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
