Cảm biến xi lanh IFM MR0101

805.000

SKU: MR0101
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

Báo giá
Mã: MR0101 Danh mục: ,
Product characteristics
Electrical design PNP/NPN
Output function normally open
Dimensions [mm] 30.5 x 5 x 6.5
Electrical data
Operating voltage [V] 5…50 AC / 5…60 DC; (UL supply class 2: 5…60 DC / 5…30 AC)
Protection class III
Reverse polarity protection yes
Outputs
Electrical design PNP/NPN
Output function normally open
Max. voltage drop switching output DC [V] 5
Max. voltage drop switching output AC [V] 5
Permanent current rating of switching output AC [mA] 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.)
Permanent current rating of switching output DC [mA] 100; (External protective circuit for inductive load (valve, contactor, etc.) necessary.)
Switching frequency AC [Hz] 1000
Switching frequency DC [Hz] 1000
Max. switching power [W] 10
Short-circuit proof no
Overload protection no
Detection zone
Response sensitivity [mT] 2.1
Travel speed [m/s] 10
Accuracy / deviations
Hysteresis [mm] 1
Repeatability [mm] -0.2…0.2
Response times
Max. fall time [ms] 0.1
Max. make time incl. bounce [ms] 0.6
Operating conditions
Ambient temperature [°C] -25…70
Protection IP 65; IP 67
Mechanical data
Weight [g] 12
Mounting flush mountable
Cylinder type T-slot cylinders
Dimensions [mm] 30.5 x 5 x 6.5
Materials housing: PA; fastening clamp: stainless steel
Switching cycles when connected to PLC [Mio] < 40
Displays / operating elements
Display
switching status 1 x LED, yellow
Electrical connection
Required protection miniature fuse to IEC60127-2 sheet 1; ≤ 0,175 A; fast acting
Accessories
Accessories (supplied)
rubber placeholder: 1
Cable clip: 1
Remarks
Remarks
No LED function in case of polarity reversal in DC operation.
operating voltage “supply class 2” according to UL
Pack quantity 1 pcs.
Electrical connection – plug
Cable: 0.3 m, PUR
Connector: 1 x M8; Locking: snap-fit

Thông tin bổ sung

Thương hiệu
Thời gian bảo hành

5 Năm

Điện áp ngõ vào
Ngõ ra

NO, NPN, PNP
