MÀN HÌNH CẢM ỨNG HMI DELTA DOP 7″ (800*480) 65,536 COLORS TFT, CORTEX-A8 800MHZ CPU, 256 MB RAM, 256 MB ROM, BUILT-IN ETHERNET, 2 COM PORT / 1 EXTENSION COM PORT, USB HOST, USB CLIENT, CE / UL CERTIFIED, OPERATION TEMPERATURE: 0℃ ~ 50℃, STORAGE TEMPERATURE: -20℃ ~ 60℃, PRESSING TIMES: >10,000K TIMES
Delta DOP-100
| MODEL | THÔNG SỐ |
|---|---|
| DOP-103BQ | 4,3 inch,1 Com, WQVGA TFT (480x) |
| DOP-103WQ | 4,3 inch ,1 Com,1 Ethernet,WQVGA TFT(480x ) |
| DOP-103WQZ0 | 4,3 inch ,1 Com,1 Ethernet,WQVGA TFT(480x ) |
| DOP-107BV | 7 inch ,1 Com, WVGA TFT (800x |
| DOP-107WV | 7 inch,1 Com,1 Ethernet, WVGA TFT (800x |
| DOP-107EV | 7 inch ,2 Com+ 1 Ethernet, WVGA TFT (800x) |
| DOP-107CV | 7 inch, 2 Com, WVGA TFT (800x |
| DOP-107DV | 7 inch,1 Com + 1 Ethernet |
| DOP-107EG | 7 inch ,2 Com+ 1 Ethernet, XGA TFT(1024x) |
| DOP-110WS | 10 inch,1 Com,1 ethernet,WSVGA TFT (1024x) |
| DOP-110IS | 10 Inch,3 com,2 Etherrnet |
| DOP-110CS | 10 inch,2 Com,WSVGA TFT (1024x) |
| DOP-112WX | 12.1 inch, 2 Com,2 Ethernet |
| DOP-115WX | 15 inch, 2 Com,2 Ethernet |
Cách lựa chọn HMI Delta DOP-100 series
