Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, NPN, M8 connector models, Red LED (660 nm)
| Loại | Standard photoelectric sensor (built-in amplifier) |
| Hình dáng | Rectangular type |
| Phương pháp phát hiện | Retro-reflective |
| Nguyên lý phát hiện | Polarization filter |
| Khoảng cách phát hiện | 0.1…4 m |
| Đối tượng phát hiện tiêu chuẩn | Opaque |
| Kích thước vật phát hiện tiêu chuẩn | D75 mm |
| Nguồn sáng | Red LED |
| Nguồn cấp | 10…30 VDC |
| Cài đặt độ nhạy | Adjuster |
| Loại đầu ra | NPN |
| Chế độ hoạt động | Dark ON, Light ON |
| Thời gian đáp ứng | 1 ms |
| Kiểu hiển thị | LED indicator |
| Mạch bảo vệ | Output short-circuit protection, Power supply reverse polarity protection, Output reverse polarity protection |
| Chức năng | Light-ON/Dark-ON selectable, Mutual interference prevention |
| Truyền thông | No |
| Vật liệu vỏ | Stainless steel |
| Phương pháp lắp đặt | Surface mounting |
| Phương pháp kết nối | Connector |
| Môi trường hoạt động | Chemical resistance, Detergent resistance, Disinfectant resistance, Water resistance |
| Nhiệt độ môi trường | -25…55 °C |
| Độ ẩm môi trường | 35…85 %RH |
| Khối lượng tương đối | 40 g |
| Chiều rộng | 10.8 mm |
| Chiều cao | 39.2 mm |
| Chiều sâu | 21 mm |
| Cấp bảo vệ | IP67, IP69K |
| Tiêu chuẩn áp dụng | CE |
| Phụ kiện đi kèm | Not equipped |
| Phụ kiện mua rời | Bracket: E39-L104, Bracket: E39-L142, Bracket: E39-L144, Bracket: E39-L150, Bracket: E39-L151, Bracket: E39-L153, Bracket: E39-L43, Bracket: E39-L44, Bracket: E39-L98, Cable: XS3F-E421-402-A, Cable: XS3F-E421-405-A, Cable: XS3F-E422-402-A, Cable: XS3F-E422-405-A, Reflectors: E39-R1, Reflectors: E39-R10, Reflectors: E39-R1K, Reflectors: E39-R1S, Reflectors: E39-R2, Reflectors: E39-R3, Reflectors: E39-R9, Reflectors: E39-RS1, Reflectors: E39-RS2, Reflectors: E39-RS3 |
Omron E3ZM
Bảng hướng dẫn lựa chọn Cảm biến quang Omron E3ZM Series| Model | Mô tả | Điện áp |
|---|---|---|
| E3ZM-D62 2M | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Infrared LED (860 nm) | 12-24V |
| E3ZM-D62 5M | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Infrared LED (860 nm) | 12-24V |
| E3ZM-D67 | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, NPN, M8 connector models, Infrared LED (860 nm) | 12-24V |
| E3ZM-D82 2M | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Infrared LED (860 nm) | 12-24V |
| E3ZM-D82 5M | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Infrared LED (860 nm) | 12-24V |
| E3ZM-D87 | Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 1 m, Light-ON/Dark-ON selectable, PNP, M8 connector models, Infrared LED (860 nm) | 12-24V |
| E3ZM-LS61H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Red LED (650 nm) | 12-24V |
| E3ZM-LS61H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Red LED (650 nm) | 12-24V |
| E3ZM-LS62H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS62H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS64H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS64H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS66H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, NPN, M8 connector models, Red LED (650 nm) | 12-24V |
| E3ZM-LS67H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, NPN, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-LS69H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, NPN, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-LS81H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Red LED (650 nm) | 12-24V |
| E3ZM-LS81H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Red LED (650 nm) | 12-24V |
| E3ZM-LS82H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS82H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS84H 2M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS84H 5M | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-LS86H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 100 mm, Light-ON/Dark-ON selectable, PNP, M8 connector models, Red LED (650 nm) | 12-24V |
| E3ZM-LS87H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 150 mm, Light-ON/Dark-ON selectable, PNP, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-LS89H | BGS reflective (fixed distance), Sensing distance White paper 100 x 100 mm: 10 to 200 mm, Light-ON/Dark-ON selectable, PNP, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-R61 2M | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-R61 5M | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-R66 | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, NPN, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-R81 2M | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Red LED (660 nm) | 12-24V |
| E3ZM-R81 5M | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Red LED (660 nm) | 12-24V |
| E3ZM-R86 | Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 100 mm to 4 m, Light-ON/Dark-ON selectable, PNP, M8 connector models, Red LED (660 nm) | 12-24V |
| E3ZM-T61 2M | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T61 5M | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T63 2M | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T63 5M | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (5 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T66 | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, NPN, M8 connector models, Infrared LED (870 nm) | 12-24V |
| E3ZM-T68 | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, NPN, M8 connector models, Infrared LED (870 nm) | 12-24V |
| E3ZM-T81 2M | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T81 5M | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T83 2M | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (2 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T83 5M | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, PNP, Pre-wired models (5 m), Infrared LED (870 nm) | 12-24V |
| E3ZM-T86 | Through-beam type, Sensing distance 15 m, Light-ON/Dark-ON selectable, PNP, M8 connector models, Infrared LED (870 nm) | 12-24V |
| E3ZM-T88 | Through-beam type, Sensing distance 0.8 m, Light-ON/Dark-ON selectable, PNP, M8 connector models, Infrared LED (870 nm) | 12-24V |
