| Product characteristics | |||
|---|---|---|---|
| Output function | normally closed | ||
| Sensing range [mm] | 20 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M30 x 1.5 / L = 81 | ||
| Electrical data | |||
| Operating voltage [V] | 20…250 AC/DC | ||
| Current consumption [mA] | < 20 | ||
| Protection class | II | ||
| Reverse polarity protection | no | ||
| Outputs | |||
| Output function | normally closed | ||
| Max. voltage drop switching output DC [V] | 8 | ||
| Max. voltage drop switching output AC [V] | 10 | ||
| Minimum load current [mA] | 5 | ||
| Max. leakage current [mA] | 2.5 (250 V AC) / 1.7 (110 V AC) / 1.5 (24 V DC) | ||
| Permanent current rating of switching output AC [mA] | 200; (350 (…50 °C)) | ||
| Permanent current rating of switching output DC [mA] | 200; (350 (…50 °C)) | ||
| Short-time current rating of switching output [mA] | 2200; (20 ms / 0,5 Hz) | ||
| Switching frequency AC [Hz] | 10 | ||
| Switching frequency DC [Hz] | 10 | ||
| Short-circuit proof | no | ||
| Overload protection | no | ||
| Output holding time | adjustable (0…60 s ) | ||
| Detection zone | |||
| Sensing range [mm] | 20 | ||
| Sensing range adjustable | yes | ||
| Factory setting sensing range [mm] | 20 | ||
| Real sensing range Sr [mm] | 20 ± 10 % | ||
| Accuracy / deviations | |||
| Hysteresis [% of Sr] | 1…15 | ||
| Switch point drift [% of Sr] | -20…20 | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…80 | ||
| Note on ambient temperature |
| ||
| Protection | IP 65; IP 67 | ||
| Mechanical data | |||
| Weight [g] | 186.5 | ||
| Housing | threaded type | ||
| Mounting | non-flush mountable | ||
| Dimensions [mm] | M30 x 1.5 / L = 81 | ||
| Thread designation | M30 x 1.5 | ||
| Materials | PBT | ||
| Displays / operating elements | |||
| Display |
| ||
| Electrical connection | |||
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting | ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Remarks | |||
| Remarks |
| ||
| Pack quantity | 1 pcs. | ||
| Electrical connection | |||
| Connection | Cable: 2 m, PVC; 2 x 0.5 mm² | ||
Cảm biến điện dung IFM KI0061
4.980.000 ₫
SKU: KI0061
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
