| Product characteristics | |||
|---|---|---|---|
| Electrical design | PNP | ||
| Output function | normally closed | ||
| Sensing range [mm] | 15 | ||
| Housing | threaded type | ||
| Dimensions [mm] | M30 x 1.5 / L = 81 | ||
| Electrical data | |||
| Operating voltage [V] | 10…36 DC | ||
| Current consumption [mA] | 13; (24 V) | ||
| Protection class | II | ||
| Reverse polarity protection | yes | ||
| Outputs | |||
| Electrical design | PNP | ||
| Output function | normally closed | ||
| Max. voltage drop switching output DC [V] | 2.5 | ||
| Permanent current rating of switching output DC [mA] | 250 | ||
| Switching frequency DC [Hz] | 40 | ||
| Short-circuit proof | yes | ||
| Overload protection | yes | ||
| Detection zone | |||
| Sensing range [mm] | 15 | ||
| Sensing range adjustable | yes | ||
| Factory setting sensing range [mm] | 15 | ||
| Real sensing range Sr [mm] | 15 ± 10 % | ||
| Operating distance [mm] | 0…12.1 | ||
| Accuracy / deviations | |||
| Correction factor | glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 | ||
| Hysteresis [% of Sr] | 1…15 | ||
| Switch point drift [% of Sr] | -15…15 | ||
| Operating conditions | |||
| Ambient temperature [°C] | -25…70 | ||
| Protection | IP 65 | ||
| Increased immunity | yes; (increased immunity to conducted radio frequency interference) | ||
| Mechanical data | |||
| Weight [g] | 195 | ||
| Housing | threaded type | ||
| Mounting | non-flush mountable | ||
| Dimensions [mm] | M30 x 1.5 / L = 81 | ||
| Thread designation | M30 x 1.5 | ||
| Materials | PBT | ||
| Displays / operating elements | |||
| Display |
| ||
| Accessories | |||
| Accessories (supplied) |
| ||
| Remarks | |||
| Pack quantity | 1 pcs. | ||
| Electrical connection | |||
| Connection | Cable: 2 m, PVC; 3 x 0.5 mm² | ||
Cảm biến điện dung IFM KI5001
3.650.000 ₫
SKU: KI5001
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT
