Cảm biến độ nghiêng IFM JN2301

SKU: JN2301
Hãng sản xuất: IFM
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

Báo giá
Product characteristics
Dimensions [mm] 90 x 62 x 33.2
Inclination measurement
Number of measurement axes 2
Application
Application High-precision inclination measurement in 2 axes for mobile applications
Electrical data
Operating voltage [V] 9.2…30 DC
Current consumption [mA] 70; (24 V DC, 25 °C)
Max. current consumption [mA] 405; (9,2 V DC; -40 °C)
Min. insulation resistance [MΩ] 100; (500 V DC)
Protection class III
Reverse polarity protection yes
Reverse polarity protection yes
Max. initialisation time [ms] 1000
Power-on delay time [s] 300; (warm-up time)
Measuring/setting range
Measuring principle MEMS capacitive
Inclination measurement
Number of measurement axes 2
Angular range [°] -45…45
Limit frequency [Hz] 0.5…10; (parameterisable)
Accuracy / deviations
Accuracy [°] ≤ ± 0,01
Repeatability [°] ≤ ± 0,01
Resolution [°] 0.01
Temperature coefficient [1/K] ≤ ± 0,0008
Interfaces
Communication interface CAN
Number of CAN interfaces 1
Terminating resistor yes; (internal ; parameterisable)
CAN
Protocol SAE J1939
Factory settings
Baud rate: 250 kBit/s
device address (ECU): 25
Operating conditions
Ambient temperature [°C] -40…85
Storage temperature [°C] -40…85
Protection IP 65; IP 67; IP 68; IP 69K
Mechanical data
Weight [g] 414.5
Dimensions [mm] 90 x 62 x 33.2
Materials housing: diecast zinc nickel-plated
Displays / operating elements
Display
Run mode 1 x LED, green
fault 1 x LED, red
Accessories
Accessories (supplied)
Protective cover: 1
Remarks
Pack quantity 1 pcs.
Electrical connection – CAN-In
Connector: 1 x M12
Electrical connection – CAN-Out
Connector: 1 x M12
